Drive Axle for Forklift

Drive Axle Forklift - The piece of equipment that is elastically fastened to the framework of the vehicle using a lift mast is referred to as the lift truck drive axle. The lift mast attaches to the drive axle and could be inclined, by at least one tilting cylinder, around the axial centerline of the drive axle. Forward bearing components along with back bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast could likewise be inclined relative to the drive axle. The tilting cylinder is connected to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H40, H45 and H35 forklifts, that are produced by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the frame of the lift truck using many different bearings. The drive axle comprise tubular axle body together with extension arms attached to it and extend backwards. This particular type of drive axle is elastically affixed to the vehicle framework using rear bearing elements on the extension arms along with frontward bearing tools located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle are sustained through the back bearing components on the framework by the extension arms. The lift mast and the load produce the forces that are transmitted into the roadway or floor by the framework of the vehicle through the drive axle's anterior bearing components. It is important to ensure the elements of the drive axle are constructed in a rigid enough way in order to maintain immovability of the forklift truck. The bearing elements can lessen minor road surface irregularities or bumps throughout travel to a limited extent and provide a bit smoother function.
